Hydraulic Performance Curve – 3AGS1.7-109-48-500
R5500,00
Agri Solsec solar pump model 3AGS1.7-109-48-500 — a compact 500W solar submersible pump for water supply on small farms and homesteads. Refer to the hydraulic performance curve for flow and head specifications.
Description
A 500W 48V solar pump for cattle watering and small-scale irrigation. 1.7 m³/h flow at up to 109 m head, with MPPT, dry-run protection, and adjustable speed control.
500W brushless motor delivers 1700 L/h up to 109 m head — enough for cattle troughs, garden plots, and small irrigation runs without oversizing the panel array.
Just 2 × 370W solar panels (740W total) get this pump moving water. Lower up-front spend, simpler install, easier to service in a remote location.
MPPT controller wrings maximum output from the panels. Dry-run protection cuts the motor when water drops, so the pump survives empty boreholes.
- 1 × 500W 48V solar pump (3AGS1.7-109-48-500)
- 1 × MPPT controller
- 1 × User manual
Specifications
- Power: 500W (48V)
- Flow Rate: 1700 L/h (1.7 m³/h)
- Max Head: 109m
- Max Water Depth: 30m
- Recommended Use: Cattle watering, small-scale irrigation
- Solar Panels: 2 × 370W (740W total)
- Includes: Adjustable speed control, MPPT controller, dry-run protection
Specifications
Model -3AGS1.7-109-48-500
Power – 500W
Voltage – 48V
Flow rate – 1.7 m³/h (1700 L/h)
Max head – 109 m
Max water depth – 30 m
Solar panels required – 2 × 370W (740W total)
Recommended use – Cattle watering, small-scale irrigation
Includes – MPPT controller, dry-run protection, adjustable speed
Warranty – 12-month manufacturer warranty
